Principal Dimensions



• Length - 160'
• Beam - 30'
• Depth - 13'
• Draft - 8'3"





Pumps

• Fire/Bilge Pump Barnes 2020 HCU With 20 hp motor
• Bilge Pump Barnes 5CCE with 3hp motor
• Rig Water Pump Crown TS-7 with 10hp motor
• Lube Pump Viking HL 4195 AK with 3/4hp motor
• Fire Monitor Pump Crane Deming 5062 4x3x17
• Sewage Pump Crown 3CO1D with 5hp motor
• Fresh Water Pump Jacuzzi with 1hp motor





Useable Deck Space

• 95'x25' 1232 200 Long Tons



Electronics



• Radar Two Furuno FR 7112/4
• VHF Radios 3 Standard Horizon Eclipse
• Single Sideband Sea8000 with Necode
• GPS One Furuno GP 1650
• Depth Sounder One Furuno FCVN667
• Auto-Pilot One AP45-HD
• NavTech Receiver One Furuno NX-500
• Loud Hailer - One Seahail 8000





Machinery

• Main Engines 4 3512B Dita 1400hp @ 1800 RPM
• Generators Cat 3306 DNIA with 75Kw Gen
• Fire Monitor Hydraulic Cat
• Bow Truster - 150hp





Steering System

• Dual Hydraulic System Huber Hydraulic



Fire Detection and Fighting Systems

• CO2 System - Herbert Hiller
• Fire Detection System Herbert Hiller

Accomodations

• Berths - 12 Bunks
• Seating - 75 Seats
• Central Air and Heat Two 5 ton units
• Refrigerator/Freezer - One
• Chest Freezer - One
• Range - One
• Heads - Two Complete Heads





Facilities

• One Washer and Dryer
